Acura MDX Specifications
Engine of Acura MDX:
Displacement - 3.7 liter
Valve – 4-valve per cylinder, 24-valve total
Type – SOHC, V-6 cylinder
System - VTEC®,Drive-by-Wire Throttle, Electronic direct, PGM-FI multi-point injection
Engine Block – Aluminum-alloy
Compression Ratio - 11.0:1
Position - Front
Alignment - Unknown
Bore x Stroke – 90 x 96 mm (3.54 x 3.78")
Max Torque - 275 lbs.-ft. @ 5000 rpm
Max Power – 300 @ 6000 rpm
Redline - 6700 rpm
Emission – ULEV-2
Acceleration of Acura MDX:
0-100 km/h –
Top Speed –
Fuel of Acura MDX:
Fuel Consumption – City 15 / Highway 20
Crankcase - 4.5 qt / 4.3 liter
Required Oil - 9.7 qt / 9.2 liters
Cooling system capacity
Coolant System –
Fuel Tank Capacity – 21.0 gal / 79.5 liter
Fuel Type – Premium unleaded 91 octane
Electric System of Acura MDX:
Power Outlet – 12 Volt(front center console and rear cargo area)
Transmission of Acura MDX:
5-speed automatic transmission with Sequential SportShift and Grade Logic Control
Gear Ratios:
1st - 2.70
2nd - 1.61
3rd - 1.07
4th - 0.77
5th - 0.54
Reverse - 1.89
Final Drive - 4.53
Steering of Acura MDX:
Torque-sensing, variable power-assist rack-and-pinion
Steering Wheel Turns, Lock-to-Lock -
Steering Ratio -
Turning Circle, Curb-to-Curb – 37.6 ft
Suspension of Acura MDX:
Front - Independent MacPherson strut
Stabilizer without Sport Package - 23mm
Stabilizer with Sport Package - 24 mm
Rear – Independent Multi-link
Stabilizer without Sport Package - 24.2 x 3.0
Stabilizer with Sport Package - 27.2 x 4.5
Brake of Acura MDX:
Front – Disc
Rear – Disc
Body of Acura MDX:
Unit body
Advanced Compatibility Engineering (ACE)
Impact Testing
Safety / Security Features of Acura MDX:
Advanced Compatibility Engineering™ (ACE™) body structure
Impact-absorbing crumple zones (front and rear)
Side-impact door beams
Dual-stage, multiple-threshold front air bags (SRS)
Front side airbags with front seat passenger Occupant Position Detection System (OPDS)
Side curtain airbags with rollover sensor
Front seat headrests with active head restraint system
Height-adjustable 3-point front seat belts with pre-tensioners and load limiters
3-point rear seat belts
4-wheel anti-lock braking system (ABS) with Electronic Brake Distribution (EBD) and Brake Assist
Vehicle Stability Assist™ (VSA®) with traction control
Trailer Stability Assist
Xenon High-Intensity Discharge (HID) front headlights
Front fog lights
Daytime Running Lights (DRL)
Tire Pressure Monitoring System (TPMS) with location and pressure indicatorsLATCH (Lower Anchors and Tethers for CHildren) child-seat mounting system for second row seats
Child seat tether anchors for second and third row seats
Rear-window defroster with timer
Side mirror-integrated LED illumination directional turn signals
Theft-deterrent security system with electronic immobilizer
Remote entry system
Dimension of Acura MDX:
Length - 4844 mm (190.7")
Width - 1994 mm (78.5")
Height - 1733 mm (68.2")
Wheelbase – 2750 mm (108.3”)
Track (Front/Rear) - 1720 mm (67.7")/ 1714 mm (67.5")
Ground Clearance - 8.2"
Kerb Weight – without Tech. Pkg. 4548 lbs/ with Tech. Pkg. 4559 lbs / with Tech. and / Ent. Pkgs. 4588 lbs / with Sport Pkg. 4564 lbs / with Sport and Ent. Pkgs. 4597 lbs
Weight Distribution – %Front %Rear
Turning Radius -
Wheels – 18” x 8” aluminum-alloy
Tyre - P255/55 R18 104H all-season
Headroom (Front / Rear) – 995mm (39.2”) / 980 mm(38.6”)/ 907 mm (35.7")
Shoulder room (Front / Rear) - 1565 mm(61.6") / 1562 mm (61.5")/ 1450 mm (57.1")
leg room (Front/Rear) – 1048 mm (41.2”) / 983 mm(38.7”)/ 739 mm (29.1")
Hiproom (Front/rear) – 1498 mm (59.0”) / 1501 mm(59.1”)/ 1090 mm (42.9")
Passenger Volume – 142.2 cu.ft
Cargo Volume (with 2nd- and 3rd-row seats folded)– 83.5 cu.ft
Interior of Acura MDX:
AC – Tri-zone front/rear synchronized automatic climate control system with air filtration and humidity control
Cupholder – Yes
Pocket – Seatback, front and rear door
1st row seat – Passenger lower center-console compartment, 10-way adjustable power seat(driver), including a power lumbar support, Advanced seat frames and power adjustment features, 8-way power adjustable seat (passenger), two levels of heating, two-driver automatic memory system, headrest, Driver Storage, dual access armrest
2nd row seat – adjustable headrests, center armrest, Folding Seatbacks, Reclining second row seats
3rd row seat – Folding Seatbacks,
Window – auto-reverse feature, Power Windows with auto-up/down and key-off operation
Audio – 253 watts of power and seven speakers, including a sub-woofer, 6-disc in-dash CD changer, XM® Satellite Radio, CD changer uses a 24-bit D/A converter and can play CD, CD-R/RW, CD-Text, and MP3/WMA formats, A speed-dependent volume control
Bluetooth – Bluetooth HandsFreeLink
Tilt / Telescoping Steering – Yes/yes
On Board Computer – Multi-Information Display, Maintenance Minder™ system, Trip computer
Instrument – Instrument Panel Design, Tire Pressure Monitoring System, Exterior temperature indicator
Steering Wheel – Steering Wheel Controls(cruise control, audio, telephone, Multi-Information Display and available voice recognition system)
Light – HomeLink® Remote System, LED overhead map lights (front, second and third row seating), Ambient cabin lighting with driver and front passenger footwell lighting, Door-mounted courtesy lights, Cargo area lighting
Exterior of Acura MDX:
Antenna – Rear spoiler
Glass – Rear-window defroster with timer
Headlight – Auto on/off Xenon HID Headlights
Foglight –
Rear Light –
Wiper - Speed-sensing, variable intermittent windshield wipers, Rear-window wiper with intermittent wipe function
Door Mirror - Heated outside mirrors with Reverse gear tilt-down function and integrated directional turn signals
Door Handle –
Bumper –
Others of Acura MDX:
Power moonroof with auto-reverse feature, auto-open/close, key-off operation
Remote activated, auto-open side windows and moonroof "quick vent" function
Key Fob Functions
Passenger Storage
Integrated dual-outlet exhaust
Body-colored tailgate spoiler
HomeLink® Remote System
Leather-wrapped steering wheel and gearshift knob
Rear-spoiler integrated radio antenna
Carpeted floor mats
Driver and passenger illuminated sun-visor-mounted vanity mirrors
Simulated Koa wood-grained interior trim
Aluminum threshold garnish
Cruise control
Options of Acura MDX:
Technology Package
Acura Navigation System9
Voice Recognition System
AcuraLink® Real-Time Traffic12
Acura/ELS Surround® Sound System
GPS-linked, solar-sensing climate control9
Bluetooth®11 HandsFreeLink® phonebook exchange
Remote-linked power-operated tailgate
Technology Package with Entertaiment Package (Adding to or replacing system with Technology Package)
Acura DVD Rear Entertainment System
Dual-level heated 2nd-row outboard seats
115- volt power outlet in front center console
Sport Package (Adding to or replacing system with Technology Package)
Active Damper System sport suspension","Perforated Premium Milano Leather","Textured Interior trim","18-inch five-spoke alloy wheels
Sport Package with Entertaiment Package (Adding to or replacing system with Sport Package)
Acura DVD Rear Entertainment System","Dual-level heated 2nd-row outboard seats","115-volt power outlet in front center console
